17
CONNECT VENT
1. Connect vent to exhaust outlet
Using a 4" (102 mm) clamp, connect vent to exhaust outlet
in dryer. If connecting to existing vent, make sure vent is
clean. Dryer vent must t over dryer exhaust outlet and inside
exhaust hood. Check that vent is secured to exhaust hood
with a 4" (102 mm) clamp.
Move dryer to nal location
2.
Move dryer to nal location. Avoid crushing or kinking vent.
After dryer is in place, remove cardboard from under dryer.
LEVEL DRYER
Level Dryer
1.
Not Level LEVEL Not Level
Check levelness of dryer from side to side. Repeat from
front to back.
NOTE: The dryer must be level for the moisture sensing system
to operate correctly.
Place
level here
Place
level here
If dryer is not level, prop up using a wood block, use wrench
to adjust legs by backing out the foot as needed, then checking
again for levelness. Once legs are level, make sure all four legs
are snug against the oor.
Adjust leveling legs
2.
