McIntosh MC205 User Manual

13
How to Connect for a Five Channel and Zone B System
Zone B Left
Loudspeaker
Center Front
Loudspeaker
Left Surround
Loudspeaker
Right Surround
Loudspeaker
+
-
+
-
+
-
To AC Outlet
+
-
+
-
Right Front
Loudspeaker
Left Front
Loudspeaker
McIntosh Two Channel Power Amplifier
Zone B Right
Loudspeaker

McIntosh MC205 Specifications

General

Damping factor	140
Amplifier class	-
Frequency range	10 - 100000 Hz
RMS rated power	1000 W
Output impedance	8 Ω
Audio output channels	5.0 channels
Peak power per channel	200 W
Signal-to-Noise Ratio (SNR)	112 dB
Total Harmonic Distortion (THD)	0.005 %
XLR in	Yes
Audio (L/R) out	10
Line inputs (RCA)	5
Speakers connectivity type	Binding post
Purpose	Home
Product color	Black
Connectivity technology	Wired
Maximum current	10 A
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Package weight	51800 g

Weight and Dimensions

Depth	533 mm
Width	444.5 mm
Height	239.7 mm
Weight	44200 g
