McIntosh MCT500 User Manual

8
POWER CONTROL IN receives
turn-on signals from a McIntosh
component and POWER CONTROL
OUT sends turn-on signals on to
another McIntosh Component
Connect the MCT500 power cord to a live
AC outlet. Refer to information on the
back panel of your MCT500 to determine
the correct voltage for your unit
IR IN for connecting an
IR Receiver
DATA IN receives control data
from a McIntosh Control Center
OPTICAL and COAXIAL DIGITAL
AUDIO OUTPUTS send a PCM
Digital Audio Signal to a Preampli-
fier or an A/V Control Center to
decode the signal into analog audio
Rear Panel Connections
XLR DIGITAL AUDIO OUTPUT
sends a PCM Digital Signal to a
Preamplifier with internal D/A
Converter to decode the signal into
analog audio
MCT DIGITAL AUDIO OUT-
PUT sends PCM or SACD Digital
Signal to a Preamplifier with
internal D/A Converter to decode
the signal into analog audio
