1-6

INSTALLATION DIAGRAM

Drain Piping

Front Panel

Air Filter

(behind the grille)

Air Intake Grille

Air Discharge

Air Discharge Louver

Air Intake

Thermal Insulation

Wrap the insulated pipe with the

ﬁ nishing tape from bottom to top

Indoor Unit

Outdoor Unit

1 EN 5CKYER-1009(1).indd 61 EN 5CKYER-1009(1).indd 6 4/21/11 9:11:18 AM4/21/11 9:11:18 AM
