Mecer IVR-1200MPPT User Manual

15
7. Specifications
MODEL
IVR-1200MPPT
IVR-2400MPPT
CAPACITY
1200VA/1000W
2400VA/1800W
POWER FACTOR
0.83
0.75
INPUT
Voltage
220-240 VAC
Voltage Range
90-280 VAC
Nominal Operating Frequency
50/60Hz
Maximum Input Current
10A
13A
OUTPUT
Nominal Output Voltage
220-240 VAC
Voltage Regulation (Batt. Mode)
+/-10%
Output Frequency Range
50/60Hz
Nominal Output Current
5.2A
10.4A
Inrush Current
10A
13A
Maximum Output Fault Current
6.9A
13.6A
Transfer Time
20 ms typical
Waveform
Simulated Sine Wave
BATTERY
Battery Voltage
12 VDC
24 VDC
Maximum Battery Discharging Current
100A
90A
Floating Charge Voltage
13.7 VDC ± 0.5 VDC
27.4 VDC ± 1 VDC
CV Charging
Voltage
Lead Acid Battery
14.3 VDC ± 0.5 VDC
28.6 VDC ± 1 VDC
Lithium Battery
14.6 VDC ± 0.5 VDC
29.2 VDC ± 1 VDC
Cut Off Voltage
10.5 VDC ± 0.5 VDC
21.0 VDC ± 1 VDC
Maximum AC Charging Current
10 A or 25 A
10 A or 25 A
SOLAR CHARGER
Solar Charger Type
MPPT
Maximum PV Array Open Circuit Voltage
100 VDC
MPP Range @ Operating Voltage
15 ~ 80 VDC
30 ~ 80 VDC
Max. PV array Input Power
825W
1650W
Max. PV array Power to support
660W
1320W
Maximum Solar Charging Current
55 A
55 A
Maximum Charging Current
(Utility +SCC)
55 A
55 A
PHYSICAL
Dimension (DxWxH) mm
272 x 212 x 127
Net Weight (kgs)
4.5
4.8
Protective Class
I
Ingress Protection Rating
IP20
ENVIRONMENT
Humidity
0 ~ 90% RH (No condensing)
Operating Temperature
0 ~ 55°C
Altitude
0 ~ 1000 m
