424
Practical hints
Flat tire
2 Jack
3 Take-up bracket
왘 Place jack 2 on firm ground.
왘 Position jack 2 under take-up
bracket 3 so that it is always vertical
(plumb-line) as seen from the side,
even if the vehicle is parked on an
incline.
왘 Jack up the vehicle until the wheel is a
maximum of 1.2 in (3 cm) from the
ground. Never start engine while
vehicle is raised.
Removing the wheel
1 Alignment bolt
왘 Unscrew upper-most wheel bolt and
remove.
왘 Replace this wheel bolt with alignment
bolt 1 supplied in the tool kit.
왘 Remove the remaining bolts.
왘 Remove the wheel.
Warning! G
The jack is intended only for lifting the vehi-
cle briefly for wheel changes. It is not suited
for performing maintenance work under the
vehicle.
ì•« Never start the engine when the vehicle
is raised.
ì•« Never lie down under the raised vehicle.
!
Do not place wheel bolts in sand or dirt.
This could result in damage to the bolt
and wheel hub threads.
