445
Practical hints
Replacing wiper blades
Installing wiper blades
1 Recess
2 Tab
3 Locking
4 Taper piece
5 Square recess
왘 Lift up the wiper arm as far as you need
to position the wiper blade under the
wiper arm and hold it.
왘 Carefully fold the wiper arm back and
make sure that the taper piece 4
slides into the recess 1 at the wiper
blade.
왘 Slide the tab 2 back in the direction of
arrow 3 until it audibly engages.
The wiper blade is locked.
!
Make certain that the square recess 5
on the taper piece 4 is on the top, oth-
erwise the taper piece 4 can not slide
in the recess 1 at the wiper blade. If
the square recess 5 is not at the top
turn the taper piece 4 around to bring
the square recess 5 to the top.
!
Hold on to the wiper arm when folding
the wiper arm back. If released, the
force of the impact from the tensioning
spring could crack the windshield.
Make certain that the wiper blades are
properly installed. Improperly installed
wiper blades may cause windshield
damage.
