448
Practical hints
Flat tire
1 Wheel wrench
왘 On wheel to be changed, loosen but do
not yet remove the wheel bolts (ap-
proximately one full turn with wrench).
The jack take-up brackets are located di-
rectly behind the front wheel housings and
in front of the rear wheel housings.
2 Jack
3 Take-up bracket
왘 Place jack 2 on firm ground.
왘 Position jack 2 under take-up
bracket 3 so that it is always vertical
(plumb-line) as seen from the side,
even if the vehicle is parked on an
incline.
왘 Jack up the vehicle until the wheel is a
maximum of 1.2 in (3 cm) from the
ground. Never start engine while
vehicle is raised.
Warning! G
The jack is intended only for lifting the vehi-
cle briefly for wheel changes. It is not suited
for performing maintenance work under the
vehicle.
ì•« Never start the engine when the vehicle
is raised.
ì•« Never lie down under the raised vehicle.
