27
At a glance
Instrument cluster
Item Page
1 L Left turn signal
indicator lamp
2 To dim instrument cluster
illumination
157
3 Reset button 156
4 To brighten instrument clus-
ter illumination
157
5 K Right turn signal
indicator lamp
6 Clock
Item Page
7 Speedometer with:
- Antilock Brake
System (ABS)
indicator lamp
420
’ Variable speed limiter
indicator lamp
1
l Distance warning
lamp
2
1
Lamp without function. It illuminates when the
ignition is on. It should go out when the engine is
running.
2
Vehicles without Distronic*: Warning lamp without
function. It illuminates when the ignition is on.
It should go out when the engine is running.
Item Page
; Brake warning lamp,
USA only
421
3 Brake warning lamp,
Canada only
421
v Electronic Stability
Program (ESP
®
)
warning lamp
425
H Combination low tire
pressure/TPMS
malfunction telltale,
USA only
Low tire pressure
telltale*, Canada only
428
428
