Clip hook 3 onto drip rail 4.
Cup holder
Opening the cup holder in the rear armrest
*
NOTE Damage to the cup holder
When the rear armrest is folded back the cup
holder could become damaged.
#
Only fold the rear armrest back when
the cup holder is closed.
#
Press cup holder 1 or 2.
#
Place a container in or remove a container
from cup holder 1 or 2.
Ashtray and cigarette lighter
Using the ashtray in the front center console
#
To open: briefly press the marking 4.
#
To remove the insert: grip the sides of the
insert 1, push it forward and pull it out
upwards 2.
#
To re-install the insert: press insert 1 into
the drawer until it engages.
#
To close: press the stowage compartment
3 closed until it locks.
104
Seats and stowing
