You can remove each stowage compartment to
increase the size of your vehicle's load com-
partment.
X
To remove: slide seat/berth combination ?
as far back as possible (Y page 103).
X
Pull stowage compartment = out to the stop.
X
Pull left-hand plastic tongue : down and
right-hand plastic tongue : up, when viewed
in the direction of travel. At the same time pull
out stowage compartment = a little each
time.
The corresponding stop is released.
i
The direction in which the plastic tongues
must be moved to release the stops is stam-
ped in the guide rail.
X
Pull out stowage compartment =.
X
To fit: slide seat/berth combination ? as far
back as possible (Y page 103).
X
Slide stowage compartment = into guide
rail ; under the seat/berth combination.
Plastic tongues : engage automatically.
Sun visors
Overview
:
Mirror light
;
Holder
=
Retaining clip, e.g. for a car park ticket
?
Vanity mirror
A
Mirror cover
Vanity mirror in the sun visor
X
Fold up mirror cover A.
X
Turn the key to position 1 or 2 in the ignition
lock.
Mirror light : lights up.
Glare from the side
X
Fold the sun visor down.
X
Pull the sun visor out of bracket ;.
X
Swing the sun visor to the side.
Folding table
Important safety notes
G
WARNING
If objects, luggage or loads are not secured or
not secured sufficiently, they could slip, tip
over or be flung around and thereby hit vehicle
occupants. There is a risk of injury, especially
when braking or abruptly changing directions.
Always store objects so that they cannot be
flung around. Secure objects, luggage or
314
Folding table
Stowing and features
