MAINTENANCE
114
3. Place a block of wood between gearcase and propeller to hold
propeller and remove propeller nut.
ob01672
4. Pull propeller straight off shaft. If propeller is seized to the shaft
and cannot be removed, have the propeller removed by an
authorized dealer.
5. To aid in future removal of the propeller, liberally coat the
propeller shaft splines with one of the following Mercury/
Quicksilver products:
Tube Ref No. Description Where Used Part No.
94
Anti-Corrosion
Grease
Propeller shaft
splines
92-802867A1
95
2-4-C Marine
Lubricant with Teflon
Propeller shaft
splines
92-802859A1
6. Flo-Torq II Drive Hub Propellers - Install forward thrust hub,
replaceable drive sleeve, propeller, thrust hub, propeller nut
retainer and propeller nut onto the shaft.
b
c
a
d
f
e
ob00421
a - Propeller nut
b - Propeller nut retainer
c - Thrust hub
d - Propeller
e - Replaceable drive
sleeve
f - Forward thrust hub
