Fuse/Relay
Location
Fuse Amp
Rating
Power Distribution Box
Description
6 40A** Rear window defroster, Heated
mirrors
7 40A** PETA Pump (PZEV engine only)
8 — Not used
9 20A** Wipers
10 20A** ABS Valves
11 20A** Heated seats
12 — Not used
13 — Not used
14 15A* Ignition switch
15 — Not used
16 15A* Transmission
17 20A* Console power point
18 10A* Alternator sense
19 40A** Logic feed to SJB (solid state
devices)
20 — Not used
21 — Not used
22 — Not used
23 60A** SJB power feed (fuses 1, 2, 4, 10, 11)
24 15A* Fog lamps
25 10A* A/C Compressor clutch
26 — Not used
27 — Not used
28 — Not used
29 60A*** Engine cooling fan
30 30A** Fuel pump relay feed
31 — Not used
32 30A** Driver power seat
33 20A** Moonroof
34 — Not used
2006 Milan (mln)
Owners Guide (post-2002-fmt)
USA (fus)
Roadside Emergencies
177
To Next Page
