Mercury 5 4-Stroke User Manual

MAINTENANCE
38
ob00424
Spark Plug
Spark plug gap 0.9 mm (0.035 in.)
4. Before installing spark plug, clean off any dirt on the spark plug seat. Install plug finger tight, and then tighten
1/4 turn or torque to specifications.
Description Nm lb. in. lb. ft.
Spark plug 27 20
Lubrication Points
1. Lubricate the following with Quicksilver or Mercury Precision Lubricants 2-4-C with Teflon or Special Lubricant
101.
• Co-Pilot - Lubricate threads.
• Swivel Bracket - Lubricate through fittings.
a
b
a
ob00491
a - Swivel bracket b - Co-pilot
• Transom Clamp Screws - Lubricate threads.
ob00492
NOTE: Lubricating the tiller handle bushing and shift handle detent requires disassembly of the product. These
points should be lubricated at least once a year by an authorized dealer.
• Tiller Handle Rubber Bushing - Lubricate internal diameter.
