FEATURES & CONTROLS
25
Remote Control Features
Your boat may be equipped with one of the Mercury Precision or Quicksilver remote controls shown. If not, consult
your dealer for a description of the functions and operations of the remote control.
a - Control handle - forward, neutral, reverse.
b - Neutral release lever
c - Trim/tilt switch (if equipped). - Refer to Features & Controls - Power Trim and Tilt.
d - Lanyard stop switch - Refer to General Information - Lanyard Stop Switch.
e - Lanyard - Refer to General Information - Lanyard Stop Switch.
f - Throttle friction adjustment - Console controls require cover removal for adjustment.
g - Ignition key switch - off, on, start.
h - Fast idle lever - Refer to Operation - Starting the Engine.
i - Throttle only button - Refer to Operation - Starting the Engine.
Warning System
The outboard warning system incorporates a warning horn inside the boat. The warning horn may be located inside
the remote control or under the dash connected to the ignition key switch.
a - Horn inside remote control b - Horn inside key switch
WARNING SYSTEM OPERATION
If the engine overheats or the oil pressure drops too low, the warning system will be activated. The warning horn
will sound continuously and engine speed will be limited to 3000 RPM.
