Wheeltech M48 GT electric scooter Part Code: Z40962-00
Owner’s Handbook Page 19 of 19
8. TROUBLESHOOTING AND SPECIFICATION
TROUBLESHOOTING
You can inspect the scooter using the checklist below before consulting your dealer. If you cannot solve
the problem by yourself contact your dealer.
Symptom Remedy
The scooter will not switch on.
• Recharge the batteries.
• Check / reset the circuit breaker in the scooter.
• Check the battery and loom connections.
The scooter switches on, but the
scooter will not move.
• Ensure there is enough power in the batteries. If not, recharge the
batteries.
• Ensure the freewheel lever is engaged in the DRIVE position.
The scooter appears slow.
• Check the battery power level and recharge.
• Check the speed dial is not set to slow, and that indoor / outdoor
switch is set to the faster setting (if applicable).
The seat turns when in operation
• Slowly rotate the seat until it drops in to place and is secure
The tiller handlebar appears loose
• Tighten the tiller adjustment handle to secure the handlebar.
Scooter will not drive and the left
hand panel on the battery gauge
will flash a sequence code.
• Ensure the wigwag paddle is released.
• Switch the scooter off and on using the ignition key.
• Recharge the batteries.
• If the problem persists, contact your dealer.
Mercury M48GT Specification Mercury M48GT Specification (cont’d)
Dimensions 1560 x 740 x 920mm Brake system Electromagnetic, with
(L x W x H) 61½” x 29” x 36¼” Secondary cable brake
Weight With battery: 168kg / 370lb Front tyre 2No. 4.00-5 grey pneumatic
Without battery: 116kg / 255lb Rear tyre 2No. 4.00-5 grey pneumatic
Battery 2No. 12V 75ah (100ah option) Charger 8A 24V DC
Motor 750W Max. speed 8mph / 12.8kph
Control system By wigwag paddle Climbing angle 10° / 1 in 6 maximum
Drive system Direct drive to the rear wheels Cruising range 30 mile / 48km
(with transaxle) Max. user weight 250kg / 39 stones
