Portable 2000 count digital multimeter
21
4. G
ENERAL SPECIFICATIO
NS
•
Mechanical
features
:
Dimensions : 170 x 80 x 35 mm
Weight (with battery) : 285 g
•
Packing
: Dimensions : 230 x 155 x 65 mm
Weight : 385 g
•
Pow
er supply
: 1 battery 9 V (type 6LF22 or 6LR61)
Battery life : approx. 300 hours with battery 6LR61
« BAT » : battery discharge indicator
•
Buzzer
: continuous beep for the continuity test
intermittent beep each time the switch is operated or
keys are pressed, and for overload indication
Response time < 500 ms
•
Climatic
conditions
:
Reference temprature : 23°C ± 5°C
Operating temperature : 0°C to 45°C
Use temperature : 0°C to 50°C
Storage Temperature : -20°C to 60°C
Relative humidity : use <
80 %
storage <
95 %
Protection rating : IP 40
•
Safety
: IEC 61010-1
Insulation : class 2
Pollution degree : 2
Indoor use
Altitude < 2000 m
CAT III, 600 V max. to earth
•
EMC
: Emission acc. EN 50081-1
Immunity acc. EN 50082-1
Influence in range 20 mV
DC
: + 2 mV
Influence in range Ohm : + 0.5 %
(end of scale)
5. A
CCESSO
RIES
5.1
Delivered with the multimeter
1 set of test leads..........................................................AG0475A
1 battery 9 V (6LF22).......................................................AL0042
1 protective elastomer case.......................................HX0002 (∗)
1 user’s manual.......................................................... 906129639
(
∗
) version « multimeter in a blister », only.
5.2 Optional
Mini-clamp..................................................................AM0089NZ
Protective elastomer case............................................... HX0002
