9. Undo the drain pump

I.Pull out the terminal

behind the drain pump.

II.Nip out clamp between

drain hose and the drain

pump, and then pull out

the drain hose.

III.Loosen the screws fitted

on the drain pump, and

then pull out the drain

pump.

10.Undo the pulley and

motor

Undo the pulley

Rotate the pulley and at

the same time pull out the

belt.

Undo the motor

I.Let the machine lie

down on the back and

then pull out the motor

wire and grounding wire.

II.Use spanner to remove

the motor screw, and lift

up the motor with the

other hand in case of

falling to the drain pump

9 UNPACKING WAYS OF MAIN PARTS
