Midea CD400 User Manual

No. Parts Specifications Materials Qty.
1 Outer casing ä=0.6mm A3
2 Insulation piece PVC1000
3
Micro switch X3M302K2KA
4 Door lock screw A3
5 Door lock bas e POM M90-04
6 Door lock spring #2 1Cr18Ni9
7 Spring washer A3
8 Linkage SECC
9 Door lock spring #1 1Cr18Ni9
10 Slider POM M90-04
11 Door lock holder SECC
12 Top rubber plate Asphalt Plate
13 Inner container assem bly AISI304
14 Rear left bracing bar SECC
15 Condenser PP T30S
16 Condenser gasket EPDM
17 Condenser nut PP T30S
18 Door gasket 2 EPDM
19 Front left bracing bar SECC
20 Spray arm assembly
21 Spray arm nut PC L-1250Y
22 Spray arm support loc knut ROM TF20
23 Spray arm base nut PP+30% fiberglass
24 Spray arm b ase gasket EPDM
25 Filter assem bly
26 Front cover bracing bar SECC
27 Door spring 1Cr18Ni9
28 Inner door cover PC L-1250Y
29 Inner door cover gasket EPDM
30 Door hook 1Cr18Ni9
31 Inner door Stainless Steel
32 Dispenser as sembly
33 Door seal Formed Rubber
34 Door left hi nge 1Cr18Ni9
35 Pulley POM M90-04
36 Outer door ABS LG HI-121H
37 Outer door cover Clear AS 117L200
38 Door gasket EPDM
39 Pulley axial A3
40 Door right hinge 1Cr18Ni9
41 Thermostat #1 clamp SECC
42 Thermostat #1
43 Heating elem ent mounting plate SECC
44 Heating elem ent gasket Silicone Rubber
45 Heating elem ent
9
WP5E Parts List

Midea CD400 Specifications
