Midea CS11M-09HRFN1-MX0W User Manual

11
5. Wiring Diagram
(Pls refer the wiring diagram on the unit)
6 Installation Details
6.1 Wrench torque sheet for
installation
Outside diameter
Torque
Additional tightening
torque
Ф6.35mm
1/4in
1500N.cm(153kgf.cm)
1600N.cm(163kgf.cm)
Ф9.52mm
3/8in
2500N.cm(255kgf.cm)
2600N.cm(265kgf.cm)
Ф12.7mm
1/2in
3500N.cm(357kgf.cm)
3600N.cm(367kgf.cm)
Ф15.9mm
5/8in
4500N.cm(459kgf.cm)
4700N.cm(479kgf.cm)
Ф19mm
3/4in
6500N.cm(663kgf.cm)
6700N.cm(683kgf.cm)
6.2 Connecting the cables
The power cord should be selected according
to the following specifications sheet.
Appliance Amps
AWG Wire Size
10
18
13
16
18
14
25
12
30
10
The cable size and the current of the fuse or
switch are determined by the maximum
current indicated on the nameplate which
located on the side panel of the unit. Please
refer to the nameplate before selecting the
cable, fuse and switch.
6.3 Pipe length and the elevation
Models
Pipe size
Gas
Liquid
MS11M-09HRFN1-BW0W+ MOB30-09HFN1-BW0W
3/8in
(Ф
9.52mm)
1/4in
(Ф
6.35mm)
CS11M-09HRFN1-MX0W(A)+ MOB30-09HFN1-MX0W
MS11M-09HRFN1-MZA5W(A)+ MOCA30-09HFN1-MZ65W
1/2in
(Ф
12.7mm)
1/4in
(Ф
6.35mm)
MS11M-09HRFN1-MZ65W(A)+ MOCA30-09HFN1-MZ65W
MS11M-12HRFN1-MZ10W+ MOCA30-12HFN1-MZ10W
MS11M-12HRFN1-BV0W+ MOB30-12HFN1-BV0W
MS11M-12HRFN1-MZ50W(A)+ MOCA30-12HFN1-MZ10W
CS11M-12HRFN1-MU5W+ MOB30-12HFN1-MV0W
MS11M-17HRFN1-MW0W+ MCA30-17HFN1-MW0W
CS11M-18HRFN1-MT0W+ MOCA30-18HFN1-MT0W
CS11M-23HRFN1-MT0W+ MOD30-24HFN1-MT0W
5/8in (Ф
15.9mm)
3/8in
(Ф
9.52mm)
MS11M-30HRFN1-MR0W+ MOD30-30HFN1-MR0W
MS11M-36HRFN1-MN10W+ MOD30-36HFN1-MP0W
Models
Standard
length
Max.
Elevati
on
Max.
Length
A
Additional
refrigerant
MS11M-09HRFN1-BW0W+
MOB30-09HFN1-BW0W
7.5m
(24.6ft)
10m
(32.8ft)
25m
(82.0ft)
15g/m
(0.16oz/ft)
CS11M-09HRFN1-MX0W(A)+
MOB30-09HFN1-MX0W
MS11M-09HRFN1-MZA5W(A)+
MOCA30-09HFN1-MZ65W
MS11M-09HRFN1-MZ65W(A)+
MOCA30-09HFN1-MZ65W
MS11M-12HRFN1-MZ10W+
MOCA30-12HFN1-MZ10W
MS11M-12HRFN1-MZ50W(A)+
MOCA30-12HFN1-MZ10W
MS11M-12HRFN1-BV0W+
MOB30-12HFN1-BV0W
CS11M-12HRFN1-MU5W+
MOB30-12HFN1-MV0W
MS11M-17HRFN1-MW0W+
MCA30-17HFN1-MW0W
7.5m
(24.6ft)
20m
(65ft)
30m
(98ft)
15g/m
(0.16oz/ft)
CS11M-18HRFN1-MT0W+
MOCA30-18HFN1-MT0W
CS11M-23HRFN1-MT0W+
MOD30-24HFN1-MT0W
7.5m
(24.6ft)
25m
(82ft)
50m
(164ft)
30g/m
(0.32oz/ft)
MS11M-30HRFN1-MR0W+
MOD30-30HFN1-MR0W
MS11M-36HRFN1-MN10W+
MOD30-36HFN1-MP0W
7.5m
(24.6ft)
30m
(82.0ft)
65m
(213ft)
30g/m
(0.32oz/ft)
