Midea DLFLAA Installation Instructions

32801002001 Specifications subject to change without notice. 3
DIMENSIONS
Fig. 4 — Dimensions
"
Right Side ViewRear Side View
Front View
Bottom View
Top View
E 10.3 [262]
D 18.2 [462]
1.2 [30]
2.2 [55]
2.3 [59]
3.3 [84]
11.8 [299]
13.3 [339]
3.0 [75]
2.5 [64]
4.9 [124]
6.8 [174]
1.7 [44]
A HEIGHT 48.1 [1222]
C WIDTH 19.7 [501]
4.8 [121]
2.4 [61]
6.7 [171]
2.2 [57]
D DUCT 18.2 [462]
E DUCT 10.3 [262]
B DEPTH 21.1 [535]
0.8 [21]
0.5 [13]
0.6 [16]
18.4 [466]
19.7 [500]
Air Outlet
Air Inlet
Ø1.7 [Ø43]
Ø1.3 [Ø34]
Ø0.8 [Ø21]
Ø1.3 [Ø34]
Ø1.7 [Ø43]
Ø0.8 [Ø21]
Filter
Coil
Blower
Nominal Filter Size
20 x 16 x 1 inches
(515 x 442 x 25 mm)
Liquid Line Ø3/8 [Ø9.5]
Gas Line Ø5/8 [Ø16]
L2
L1
