MCAC-2008-11 Air-cooled Modular Chiller
11
For digital scroll heat pump 65kW module:
MGA-D( )W/SN1
Model
65 130 195 260 325 390 455 520
Combination (Main module + auxiliary
module)
Pieces 1+0 1+1 1+2 1+3 1+4 1+5 1+6 1+7
Cooling Capacity kW 65 130 195 260 325 390 455 520
Heating Capacity kW 69 139 207 276 345 414 483 552
Power supply V/Ph/Hz 380/3/50
Type Scroll (1 digital scroll plus 3 fixed speed)
Compressor
Quantities Pieces 4 8 12 16 20 24 28 32
Cooling kW 21.5 43 64.5 86 107.5 129 150.5 172
Power input
Heating kW 21 42 63 84 105 126 147 168
Type R410A R410A R410A R410A R410A R410A R410A R410A
Refrigerant
Weight kg 14 14×2 14×3 14×4 14×5 14×6 14×7 14×8
Air side heat-exchanger type Copper-fin-coil
Quantities of fan motor Pieces 2 4 6 8 10 12 14 16
Air flow volume ×10
3
m
3
/h 24 24×2 24×3 24×4 24×5 24×6 24×7 24×8
Condenser
(Air side)
Fan motor input kW 0.7×2 0.7×4 0.7×6 0.7×8 0.7×10 0.7×12 0.7×14 0.7×16
Water side heat-exchanger
type
Plate type
Water resistance loss kPa 29.4 29.4 29.4 29.4 29.4 29.4 29.4 29.4
Water inlet/outlet pipeline
diameter
mm 133 133 133 133 133 133 133 133
Water flow volume m
3
/h 11.2 22.4 33.6 44.8 56 67.2 78.4 89.6
Max. Pressure MPa 1 1 1 1 1 1 1 1
Evaporator
(Water side)
Water pipe connection type Soft connection
L mm 2492 2492 2492 2492 2492 2492 2492 2492
W mm 850 2300 3750 5200 6650 8100 9550 11000
Dimension
H mm 1820 1820 1820 1820 1820 1820 1820 1820
Packing
size
L×W×H mm 2612×1034×2041
Net weight kg 700 1400 2100 2800 3500 4200 4900 5600
Weight
Operating weight kg 765 1530 2295 3060 3825 4590 5355 6120
Power wiring mm
2
×No. 10×5-core Connection
wiring
Signal wiring mm
2
×No. 0.75×3-core
Control type Wired controller
Safety protection device
High/low-pressure switch, anti-frost protection, water-flow switch, over-load protection,
and power phases sequence protection.
Power supply V/Ph/Hz 380/3/50 Electric
heater
(optional)
Power input W 15 30 45 60 75 90 105 120
Noise level dB(A) 60
Operation water temp ℃ Cooling：5～17 Heating：45～50
Ambient temp ℃ Cooling：17～48 Heating：-10～21
Note: Please refer to the water flow volume in the above table strictly to design and install.
