Midea MHA-192HWN1 User Manual

R410A 380~415V 3Ph 50Hz TempMaker Series Split AC MCAC-UTSM-2014-03
23
2. Specifications
Model
MHB-76HWN1
MHB-96HWN1
MHA-150HWN1
MHA-192HWN1
Power supply
\
220-240V~, 1Ph, 50Hz
220-240V~, 1Ph, 50Hz
Cooling
Capacity
Btu/h
76,000
96,000
150,100
192,000
W
22,300
28,100
44,000
56,300
Input
W
7,500
9,600
16,300
22,000
EER
W/W
2.97
2.93
2.70
2.56
Heating
Capacity
Btu/h
85,300
106,000
160,300
200,000
W
25,000
31,100
47,000
58,600
Input
W
8,300
10,300
15,700
19,300
COP
W/W
3.01
3.02
2.99
3.04
Rated input (Indoor unit)
W
1,300
1,400
2,730
4,690
Rated current (Indoor unit)
A
5.2
5.8
12.1
20.9
Indoor air flow (m
3
/h/CFM)
\
4,500 (2,647)
5,100 (3,000)
8,500 (5,000)
10,800 (6,354)
Indoor standard ESP
Pa
196
196
196
196
Indoor noise level
dB(A)
56
56
63
65
Refrigerant type
\
R410A
R410A
R410A
R410A
Refrigerant control
\
Capillary
Capillary
Fan
Type
\
Centrifugal fan
Centrifugal fan
Centrifugal fan
Centrifugal fan
Motor model (×Qty.)
\
YDK300-4X(×2)
YDK550-4X(×2)
YDK300-4X(×3)
YDK600-4C(×3)
Input (Hi/med/lo)
W
720/605/510
1,015/850/695
720/605/510
1,130/990/850
Capacitor
\
15μF/450V
15μF/450V
15μF/450V
20μF/450V
Speed (Hi/med/lo)
r/min
1,040/930/825
1,160/1010/860
1,040/930/825
1,280/1,135/975
Coil
Type
\
Copper tube and aluminum fin
Copper tube and aluminum fin
Tube size
mm
Ф7
Ф7
Ф7
Ф7
No. of rows
\
4
4
4
4
Fin spacing
mm
1.5
1.5
1.5
1.5
Tube pitch× row pitch
mm
21×13.37
21×13.37
21×13.37
21×13.37
Length× height
mm
1,202×378
1,202×378
1,602×588
1,602×588
Number of circuits
\
14
18
42
28
Controller
\
KJR-29B
KJR-29B
KJR-29B
KJR-29B
Refrigerant pipe (Liquid/ Gas)
mm
Ф9.52/Ф22
Ф9.52/Ф25
Ф16/Ф32
Ф16/Ф32
Power wire
\
3×2.5mm
2
3×2.5mm
2
3×2.5mm
2
3×2.5mm
2
Signal wire
\
4×1.0mm
2
4×1.0mm
2
4×1.0mm
2
4×1.0mm
2
Drain pipe size
mm
Ф41
Ф41
Ф41
Ф41
Dimension (W×H×D)
mm
1,366×450×716
1,828×668×858
Packing (W×H×D)
mm
1,555×5 00×875
2,095×800×964
Net/Gross weight
kg
94/106
96/108
208/220
215/230
Notes:
1. Rated input = Max. input, Rated current = Max. input.
2. Nominal cooling capacities are based on the following conditions:
Indoor temp: 27°CDB, 19°CWB; Outdoor temp: 35°CDB, 24°C WB; Nominal heating capacities are based on the
following conditions: Indoor temp: 20°CDB, 15°C WB; Outdoor temp: 7°CDB, 6°CWB.
