Midea MHA-192HWN1 User Manual

MCAC-UTSM-2014-03 R410A 380~415V 3Ph 50Hz TempMaker Series Split AC
54
1. Specifications
Model
MOV-76HN1-R
MOV-96HN1-R
Power supply
\
380-415V~, 3Ph, 50Hz
380-415V~, 3Ph, 50Hz
Ambient temp in cooling
°C
17～46
17～46
Ambient temp in heating
°C
-7~24
-7~24
Rated input (Outdoor unit)
W
11,700
14,400
Rated current (Outdoor unit)
A
19.3
23.7
Noise level
dB(A)
68
68
Compressor
Type ×Qty.
\
Scroll ×1
Scroll ×1
Brand
\
Copeland
Copeland
Model
\
ZP90KCE-TFD-522
ZP120KCE-TFD-522
Capacity
W
21,900
29,200
Input
W
6,950
9,200
Rated current
A
16.5
20
Locked rotor Amp
A
95
118
Refrigerant oil
ml
2,513 (POE)
3,253 (POE)
Refrigerant type/charge
\
R410A/5,400g
R410A/5,500g
Fan
Type ×Qty.
\
Axial fan ×2
Axial fan ×2
Motor model
\
YDK210-6A
YDK400-4C
Motor input (4/3 fan blades)
\
Hi: 284; Lo: 202
Hi: 621/587; Lo: 388
Capacitor
\
10μF/450V
25μF/450V
Motor speed (4/3 fan blades)
rpm
Hi: 920/930; Lo: 650/710
Hi: 1,180/1,230; Lo: 790/870
Coil
Type
\
Copper tube and aluminum fin
Copper tube and aluminum fin
Tube size
mm
Φ7
Φ7
No. of rows
\
2
2
Fin space
mm
1.3
1.3
Tube pitch(a)×row pitch(b)
mm
21×13.37
21×13.37
Coil (W×H)
mm
2,175×882
2,175×882
Number of circuits
\
18
20
Refrigerant
pipe
Liquid side/ Gas side
mm
Ф9.52/Ф22
Ф9.52/Ф25
Max. pipe length
m
50
50
Max. difference in level
\
25m(O.D. up) /30m(O.D. down)
Connection
wire
Power wire
\
5×6.0mm
2
5×10.0mm
2
Signal wire
\
4×1.0mm
2
4×1.0mm
2
Dimension (W×H×D)
mm
1,255×908×700
1,255×908×700
Packing (W×H×D)
mm
1,320×1,060×730
1,320×1,060×730
Net/ Gross weight
kg
174/193
187/204
Notes:
1. Rated input = Max. input, Rated current = Max. current.
2. Nominal cooling capacities are based on the following conditions: Indoor temp: 27°CDB, 19°CWB; Outdoor
temp: 35°CDB; Nominal heating capacities are based on the following conditions: Indoor temp: 20°CDB;
Outdoor temp: 7°CDB, 6°CWB.
