Midea MHC-V6W/D2N8-B Engineering Data

M thermal Mono
202005 101
Part 3 - Installation and Field Settings
8 Operation parameter
MENU > OPERATION PARAMETER
This menu is for installer or service engineer reviewing the operation parameters. There are nine pages for the operating
parameter as following
Figure 3-9.1: Operation parameter
OPERATION PARAMETER #01
OPERATE MODE COOL
ADDRESS
SV1 STATE ON
ONLINE UNITS NUMBER 1
SV2 STATE OFF
SV3 STATE OFF
PUMP_I ON
1/9
OPERATION PARAMETER #01
PUMP-C OFF
ADDRESS
PUMP-S OFF
PUMP-O OFF
PUMP-D OFF
PIPE BACKUP HEATER OFF
TANK BACKUP HEATER ON
2/9
OPERATION PARAMETER #01
T1 LEAVING WATER TEMP. 35°C
ADDRESS
WATER FLOW 1.72m 3/h
GAS BOILER OFF
HEAT PUMP CAPACTIY 11.52kW
POWER CONSUM. 1000kWh
Ta ROOM TEMP 25°C
3/9
OPERATION PARAMETER #01
Tw2 CIRCUIT2 WATER TEMP. 35°C
ADDRESS
TIS’ C1 CLIMATE CURVE TEMP. 35°C
T5 WATER TANK TEMP. 53°C
TIS2’ C2 CLIMATE CURVE TEMP. 35°C
TW_O PLATE W-OUTLET TEMP. 35°C
TW_I PLATE W-OUTLET TEMP. 30°C
4/9
OPERATION PARAMETER #01
Tbt2 BUFFERTANK_LOW TEMP. 35°C
ADDRESS
IDU SOFTWARE 01-09-2019V01
Tbt1 BUFFERTANK_UP TEMP. 35°C
5/9
Tsolar 25°C
OPERATION PARAMETER #01
COMP.CURRENT 12A
ADDRESS
COMP.FREQENCY 24Hz
ODU MODEL 6kW
COMP.RUN TIME 54 MIN
COMP.TOTAL RUN TIME 1000Hrs
EXPANSION VALVE 200P
6/9
OPERATION PARAMETER #01
IDU TARGET FREQUENCY 46Hz
ADDRESS
FREQUENCY LIMITED TYPE 5
FAN SPEED 600R/MIN
SUPPLY VOLTAGE 230V
DC GENERATRIX VOLTAGE 420V
DC GENERATRIX CURRENT 18A
7/9
OPERATION PARAMETER #01
TW_I PLATE W-INLET TEMP. 30°C
ADDRESS
T2 PLATE F-OUT TEMP. 35°C
TW_O PLATE W-OUTLET TEMP. 35°C
T2B PLATE F-IN TEMP. 35°C
Th COMP. SUCTION TEMP. 5°C
Tp COMP. DISCHARGE TEMP. 75°C
8/9
OPERATION PARAMETER #01
T4 OUTDOOR AIR TEMP. 5°C
ADDRESS
TF MODULE TEMP. 55°C
T3 OUTDOOR EXCHARGE TEMP. 5°C
P1 COMP. PRESSURE 2300kPa
ODU SOFTWARE 01-09-2018V01
HMI SOFTWARE 01-09-2018V01
9/9
