M thermal Mono
202005 19
Engin
eerin
g
Data
Part 2 - Engineering Data
2 Dimensions and Center of Gravity
MHC-V4W/D2N8-B / MHC-V6W/D2N8-B / MHC-V8W/D2N8-B/ MHC-V10W/D2N8-B
unit：
mm
Model
A
B
C
4/6kW
370
540
190
Midea CAC Confidential
