The shaded area represents the
wall or ceiling area for the vent
cut-out, for feeding the connection ca
-
ble through to an external fan and for
fitting the connection socket.
Connection for air extraction C 150 mm,
or C 125 mm with reducing collar.
Appliance height H = 960 – 1320 mm
Safety distance S above a cooker/hob
Safety regulations prohibit the fitting
of this cooker hood over a solid fuel
stove.
For safety reasons, the distance S
between the top of the cooker/hob
and the bottom of the cooker hood
should be at least
– 365 mm above electric/gas cook-
ers and hobs.
See "Warning and Safety instruc-
tions" for further information.
When deciding dimension S, ensure
that the minimum specified safety dis
-
tance between the cooker/hob and the
cooker hood is maintained. If the hood
is fitted flush to the ceiling, make sure
that the height of cooker / hob + S + H
is equal to but not greater than the floor
to ceiling height of the room.
Appliance dimensions
21
