Miele H 5681 BP User Manual

^
To reassemble the door:
The two middle panes are identical.
To ensure they are refitted correctly,
one of the corners is more angled
than the others.
When refitting the lower pane, the
more angled corner must be
inserted in the left hand retainer at
the bottom.
^
Replace the first of the middle panes.
The more angled corner must be at
the bottom left.
When refitting the upper pane, the
more angled corner must be
inserted at the top left.
^ Replace the second of the middle
panes with the more angled corner at
the top left.
^
Replace the seal.
Cleaning and care
65

Miele H 5681 BP Specifications

General

Oven type	Electric
Self-cleaning	Yes
Oven thermostat range	0 - 280 °C
Total oven(s) interior capacity	66 L
Timer type	Digital
Cord length	1.7 m
Control type	Sensor
Product color	Stainless steel
AC input voltage	230 V

Weight and Dimensions

Depth	555 mm
Width	600 mm
Height	595 mm
Weight	50000 g
Interior dimensions (W x D x H)	416 x 413 x 386 mm
