Read the instructions supplied before installing
and using it for the first time.
This machine must be installed and commissioned in
strict accordance with local and national safety and
building regulations by a suitably qualified engineer.
The tumble dryer must only be operated in a room
with sufficient ventilation.
Do not install the tumble dryer in a room where there
is a risk of frost occurring.
,
The machine must not be transported without
its transport pallet in position.
Once the dryer reaches its final location, use a suit-
able lifting mechanism to lift the dryer off its transport
pallet.
To ensure suitable access for future maintenance and
service work, please ensure that the minimum distan
-
ces between the dryer and the wall specified on the
installation diagram are strictly observed.
PT 825X / 833X / 840X PT 850X / 880X
x 1400 mm 1640 mm
y 906 mm 1206 mm
z 852 / 1035 / 1164 mm 1018 / 1384 mm
Installation and connection
