Removing the shipping struts
Four red-marked shipping struts, two at the
front and two at the rear, are each fixed with
3 hex screws.
^ Remove the shipping struts at the installation
location before using the washer.
^
Take off the front and back panel of the
machine by removing the screws at the
bottom edge of the front service panel and
the screws in the rear panel and remove.
Save the shipping struts for future use. They
must be refitted if the machine is moved.
Do not move the machine without all of
the outer panels in place.
Installation Instructions
40
