Connection to a sink drain outlet
The drain hose can be connected
directly to a sink drain outlet.
^ Remove the following from the back
of the dryer at the bottom:
Adapter 1 and hose clip 3 behind it.
^
Fit adapter 1 to the sink drain outlet
using nut 2.
If this nut has a flat disc sealing it you
should take the disc out first.
Important: if this nut has a washer or
seal in it this must not be removed!
^
Attach the end of the hose to adapter
1.
^
Use a screwdriver to tighten hose
clip 3 up close to the nut.
If you no longer wish to use an
external condensed water outlet:
,
Do not push the drain hose
back into the dryer. Doing this could
cause it to become kinked and
damaged in the dryer.
^ Loop the drain hose up.
^ Use a suitable cable tie to secure the
looped hose to the back of the dryer,
or simply lay the looped hose behind
the dryer.
^ Attach the open end of the drain
hose back onto the holder at the
back of the dryer at the top (see
holder 2 in "Pulling out the drain
hose").
Installation
44
