External condensed water out-
let
The condensed water can be drained off
directly if the machine is installed near a
sink, drain outlet etc.
Maximum drain hose length: 3.00
metres
Maximum delivery head: 1.00 metre
Accessories supplied:
– 2 metre drain hose
– Hose clamp
– Adapter sleeve
– Hose clip
Unscrew the hose clip from the drain
outlet at the back of the machine.
Remove the rubber plug.
Push the drain hose onto the drain
outlet.
Secure the hose firmly with the clip.
Make sure that the hose is not
kinked.
Installation
30
