Miele TWC220WP User Manual

11946850-00
Installation
*INSTALLATION*
Changing the door hinging
You can change the door hinging on
this tumble dryer yourself.
For safety reasons the tumble dryer
must be disconnected from the elec-
tricity supply before changing the
door hinging.
You will need:
- a Torx T20 and T30 screwdriver
- a flat head screwdriver or pointed pli-
ers
- the lock catch cover supplied
- the door hinge cover supplied
- a soft surface (e.g. a tablecloth)
Changing the hinging over
1. Remove the door from the dryer
 Open the door.
 Use a T30 Torx screwdriver to un-
screw the two screws on the base
plate of the door hinge .
The door cannot fall off as it is held in
place by 2 pins.
 Hold the door securely and pull it for-
wards: to remove the door you will
need to pull the base plate of the
hinge with its 2 pins out of the dryer.
To avoid scratching the door, place it
outer side downwards on a soft sur-
face (e.g. a tablecloth).
2. Change over the door lock on the
dryer
 Use a Torx T30 screwdriver to un-
screw the two screws on the door
lock .
 Use the screwdriver to press the door
lock upwards.
The door lock will spring out of its posi-
tion and can then be removed.

Miele TWC220WP Specifications

General

Door hinge	Left
Door style	Opaque door
Cord length	2 m
Control type	Rotary
Loading type	Front-load
Drying system	Heat pump
Product color	White
Built-in display	Yes
Reversible doors	No
Appliance placement	Freestanding
Delay start (max)	24 h
Current	10 A
Heat source	Electric
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy consumption	1.55 kWh
Energy efficiency scale	A+++ to D
Annual energy consumption	192 kWh
Cycle time	165 min
Noise level	66 dB
Drying class	A
Drum capacity	8 kg
Refrigerating medium	R290
Number of drying programs	12
Refrigerating medium weight	110 g

Weight and Dimensions

Depth	655 mm
Width	596 mm
Height	850 mm
Weight	52000 g
Depth with door open	1077 mm
