Miele TWV 780 WP User Manual

Fragrance flacon
58
Inserting the fragrance flacon
 Open the door of the tumble dryer.
The fragrance flacon is inserted in the
upper fluff filter. They can be fitted on
the left and the right hand side next
the opener.
 Open the cover using the tab until the
tab is right at the top as shown.
To prevent the accumulation of fluff,
the cover of the unused socket must
remain closed.
Push the tab of the cover to the bot-
tom (see arrow), until you hear it click
into position.
 Insert the fragrance flacon into the
socket as far as it will go.
Markers  and  must line up with
one another.

Miele TWV 780 WP Specifications

General

Door hinge	Left
Cord length	2 m
Control type	Rotary, Touch
Display type	LED
Loading type	Front-load
Drying system	Heat pump
Product color	White
Reversible doors	Yes
Appliance placement	Freestanding
Self-cleaning	No
Delay start (max)	24 h
Current	10 A
Heat source	Electric
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy consumption	1.47 kWh
Energy efficiency scale	A+++ to D
Annual energy consumption	174 kWh
Power consumption (standby)	0.2 W
Cycle time	220 min
Noise level	62 dB
Drying class	A
Drum capacity	9 kg
Refrigerating medium	R134a
Refrigerating medium weight	480 g

Weight and Dimensions

Depth	643 mm
Width	596 mm
Height	850 mm
Weight	62000 g
Depth with door open	1077 mm
