Miele TWV 780 WP User Manual

Installation
*INSTALLATION*
83
Additional installation require-
ments
Slot-in
This tumble dryer is suitable for pushing
under a worktop.
Appliance defect due to a build-up of
heat.
Make sure there is adequate room
for warm air from the dryer to be dir-
ected away.
- The appliance lid cannot be removed.
- The electrical socket must be located
in an accessible position near the
tumble dryer.
- Drying durations may increase
slightly.
Optional accessories
– Washer-dryer stack
The tumble dryer can be combined with
a Miele washing machine in a washer-
dryer stack. The appropriate Miele
washer-dryer stacking kit is required.
– Plinth
The tumble dryer can be fitted on a
plinth with drawer (please note the
plinth may not be available in all coun-
tries).

Miele TWV 780 WP Specifications

General

Door hinge	Left
Cord length	2 m
Control type	Rotary, Touch
Display type	LED
Loading type	Front-load
Drying system	Heat pump
Product color	White
Reversible doors	Yes
Appliance placement	Freestanding
Self-cleaning	No
Delay start (max)	24 h
Current	10 A
Heat source	Electric
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Energy consumption	1.47 kWh
Energy efficiency scale	A+++ to D
Annual energy consumption	174 kWh
Power consumption (standby)	0.2 W
Cycle time	220 min
Noise level	62 dB
Drying class	A
Drum capacity	9 kg
Refrigerating medium	R134a
Refrigerating medium weight	480 g

Weight and Dimensions

Depth	643 mm
Width	596 mm
Height	850 mm
Weight	62000 g
Depth with door open	1077 mm
