MikroTik Chateau LTE12 User Manual

Mounting
The device is designed to be used indoors, by placing it on the desktop.
The IP rating scale for this device is IP0. We recommend using Cat5 shielded cable. When using and
installing this device please pay attention to Maximum Permissible Exposure (MPE) safety distance with a
minimum of 20 cm between the radiator and your body.
Powering
The device accepts power from an adapter:
• Direct-input power jack (5.5 mm outside and 2 mm inside, female, pin positive plug) 12-28 V DC⎓.
The power consumption under maximum load can reach 17 W, with attachments 23 W.
Configuration
We recommend checking for updates frequently to receive the latest updates for your RouterOS software to ensure
the best performance and stability.
RouterOS includes many configuration options in addition to what is described in this document. We suggest
starting here to get yourself accustomed to the possibilities: http://mt.lv/help. In case IP connection is not available,
the Winbox tool (http://mt.lv/winbox) can be used to connect to the MAC address of the device from the LAN side
(all access is blocked from the Internet port by default).
For recovery purposes, it is possible to boot the device for reinstallation, see section Buttons and Jumpers.
Mode button
Mode button located on the back of the unit, to the right side (see “Expansion slots and ports”)
The Default configuration for the Mode button is dark mode - to turn off all LEDs. The button can be configured in
RouterOS to run any user specified-scripts.
Sync button
Sync button located on the top of the unit. WPS Sync button, if configured on the wireless interface, can be used to
connect new clients.
• Press and hold the WPS button for 1 – 5 seconds to enable WPS for wireless
interfaces.
See mikrotik.com/products for the latest version of this document. Page 3, Document #53138 Modified on: 26.FEB.2020

MikroTik Chateau LTE12 Specifications

General

Flash memory	16 MB
Certification	CE/RED, EAC, ROHS
Internal memory	256 MB
Processor cores	4
Built-in processor	Yes
Processor frequency	716 MHz
Ethernet WAN	No
Modulation	64-QAM, 256-QAM
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	867 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
4G standard	LTE-TDD & LTE-FDD
4G bands supported	700, 800, 850, 900, 1800, 2100, 2300, 2500, 2600 MHz
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	5
Product type	Tabletop router
Product color	Black, White
LED indicators	LAN, LTE, Power, WLAN
Output voltage	12 - 28 V
Power source type	DC
Power consumption (typical)	23 W
Operating temperature (T-T)	-40 - 70 °C
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	44 mm
Width	240 mm
Height	156 mm
