MikroTik Chateau LTE12 User Manual

Antenna usage
The device has two external antenna connectors on the back behind the doors.
• Open doors by pulling them upwards.
• Screw antenna to the SMA connector located on the left side.
When using one antenna, please connect to the SMA connector on the left side.
Only when using two antennas, you can connect to the right SMA connector.
Please connect and disconnect the antenna, when the device is turned off!
See mikrotik.com/products for the latest version of this document. Page 5, Document #53138 Modified on: 26.FEB.2020

MikroTik Chateau LTE12 Specifications

General

Flash memory	16 MB
Certification	CE/RED, EAC, ROHS
Internal memory	256 MB
Processor cores	4
Built-in processor	Yes
Processor frequency	716 MHz
Ethernet WAN	No
Modulation	64-QAM, 256-QAM
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	867 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
4G standard	LTE-TDD & LTE-FDD
4G bands supported	700, 800, 850, 900, 1800, 2100, 2300, 2500, 2600 MHz
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	5
Product type	Tabletop router
Product color	Black, White
LED indicators	LAN, LTE, Power, WLAN
Output voltage	12 - 28 V
Power source type	DC
Power consumption (typical)	23 W
Operating temperature (T-T)	-40 - 70 °C
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	44 mm
Width	240 mm
Height	156 mm
