MHP30H7JAE/2007504A (1 of 1)
ABOUT THIS MANUAL
Scope—This instruction manual is intended to provide preventive maintenance procedures,
service procedures, and mechanical parts identification for Milnor® 30022H7x and 30022H8x
model rigid mount washer-extractors. Measurements are in commonly used US and metric units
unless otherwise noted.
See the appropriate programming and operating manual for information on the control
system. See the schematic manual for electrical parts identification and electrical
troubleshooting.
Manual Number/Date Code (When To Discard or Save)—The manual
number/date code is located on the inside front cover, upper right corner just above the manual
name. Whenever the manual is reprinted with new information, part of this number changes. If
the date code after the “/” changes, the new version applies to all machines covered by the
old version, but is improved— thus the old version can be discarded. If the manual number
before the “/” changes, the new manual covers only new machines. Example: Discard
MATMODELAE/8739
CV when MATMODELAE/8739DV is received (minor improvements).
Also, discard MATMODELAE/8739DV when MATMODELAE/8746AV is received (major
improvements). But keep MATMODELAE/8746FV when MATMODELBE/8815AV is
received, since the new manual no longer applies to machines originally shipped with the old
manual.
Documents and Change Bars—The individual documents comprising this manual use the
same revision criteria as the manual. Text documents also display change bars. Example: When
sectionMSOP0599AE/9135
BV becomes MSOP0599AE/9135CV, change bars with the letter
“C” appear next to all changes for this revision. For a major rewrite (e.g.,
MSOP0599AE/92
26AV), all change bars are deleted.
For Assistance—Please call:
Pellerin Milnor Corporation Phone:(504) 467-9591
Attn: Service Department Fax:(504) 467-9777
P. O. Box 400
Kenner, LA 70063-0400
