Milnor 30022H8J - Motor Mount

R
Pellerin Milnor CorporationPellerin Milnor Corporation
P. O. Box 400, Kenner, LA 70063-0400
Litho in U.S.A.
Item
Part Number
Description
Comments
Used In
Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to
assemblies are referred to in the "Used In" column to identify which components belong to an assembly. The item
numbers (1, 2, 3, etc.) assigned to components relate the parts list to the illustration.
Parts List—Motor Mount
BMP010017/2002044V
(Sheet 2 of 2)
.
---------------------------------------------------------------------ASSEMBLIES------------------------------------------------------------------
A ADB3022H8 ASSY=DRIVE BASE LC, 3022H8
-------------------------------------------------------------------COMPONENTS------------------------------------------------------------------
all 1 02 04256 PLATE=MOTOR MNT, 3022S4
all 2 02 03839B PLATE=MTR MNT REINFORCEMENT
all 3 02 03196 BRKT=MOTOR MOUNT LC, 3022H8
all 4 02 04258 SHAFT=MOTOR MOUNT, 3022S4
all 5 54JH10750C SHFTCOLLAR 3/4" CLPTYP CFG#12S
all 6 02 04259 SPRNG/MOT MOUNT/3022S4#SPC2690
all 7 15K162 HXCAPSCR 1/2-13UNC2AX1.5 GR5 P
all 8 15U300 LOKWASHER REGULAR 1/2 ZINC PLT
all 9 15G230 HXNUT 1/2-13UNC2B SAE ZINC GR2
all 10 02 19288 BRACKET=ADJUSTING-1.5X1.75
all 11 15K092 HEXFLGSCR 3/8-16X1 GR8 CS
all 12 15U241 FLATWASHER 13/32IDX1+3/4ODX14G
all 13 15U255 LOCKWASHER MEDIUM 3/8 ZINCPL
all 14 15G198 HXFLGNUT 3/8-16 ZINC
all 15 15K154H INDHEXFLGSCR 1/2-13X1+3/4GR8ZN
all 16 02 19283 NUT=1/2-13UNCX1+1/2SQ SPEC
