Overview
1-21
Model Matched
Transduce
r(s)
Type Biopsy
Angle/Depth
(±1°)
Applicable Biopsy
Needle
NGB-031 SC5-1U
metal/needle
detachable
25°, 35°, 45° 14G, 16G, 18G, 20G, 22G
NGB-034 L9-3U/L9-
3E
metal/needle
detachable
40°, 50°, 60°
Metal: 4G, 16G, 18G,
20G, 22G
NGB-036 C4-1U
metal/needle
detachable
7°, 25°, 35°
Metal: 14G、16G、
18G、20G、22G
1.5 Composition
The following items are supplied with each transducer.
Items Quantity
Ultrasonic transducer 1
Operator’s manual 1
Syringe 1( for 6LE7(s/P), 6LB7(s), 6LB7E,
65EL60EA, 65EL66HA only)
1.5.1 Transducer Functions by Part
This section describes the name and function of each part as well as the immersible
range of the ultrasonic transducer.
The transducer is classified as "IPX7" according to the degree of protection against
harmful ingression of water (from the transducer head to the cable protector).
The connector is not waterproof and must not be immersed into liquids such as
disinfectant.
The transducer is shown as follows (take 3C5A as an example):
