Ordering Information
Model Description
FX-2000 Standard Series
FX-2003-6DS-16LED Compact Main Control Unit c/w one Intelligent Signaling Line Circuit, Four Style Z/Y (Class A/B)
Notication Appliance Circuits rated at 1.7 Amps each and a 4 line by 20 character back-lit LCD
display with 16 LEDS for annunciation (DSPL-420-16TZDS). This display is functionally equivalent
to the classic FX-2000 main display, but more compact adding in the 16 LEDs for annunciation in
addition to all the standard functions.TheFX-2003-6DS-16LED is equipped with a 6 Amp Power
Supply which charges 10-24 AH batteries. The FX-2003-6DS-16LED provides space for 3 adder
modules and 2 internal annunciator adder modules. Order UB-1024DS and DOX-1024DS(R)
separately.
FX-2003-6DS Compact Main Control Unit c/w one Intelligent Analog Loop Controller (99 Analog Sensors and 99
Addressable Modules), 4 x 20 Back-lit LCD display, 4 Class A/B (Style Z/Y) Indicating Circuits (1.7
Amps each), a 6 Amp power supply and a backbox. Supports up to 16 Conventional Adder Mod-
ules. Provides space for 3 Adder Modules and 2 internal annunciation modules. Order UB-1024DS
and DOX-1024DS(R) separately.
FX-2003-12DS Compact Main Control Unit c/w one Intelligent Analog Loop Controller (99 Analog Sensors and 99
Addressable Modules), 4 x 20 Back-lit LCD display, 4 Class A/B (Style Z/Y) Indicating Circuits (1.7
Amps each), a 12 Amp power supply and a backbox. Supports up to 16 Conventional Adder Mod-
ules. Provides space for 3 Adder Modules and 2 internal annunciation modules. Order UB-1024DS
and DOX-1024DS(R) separately.
FX-2017-12ADS Mid-Size Main Control Unit c/w one Intelligent Analog Loop Controller (99 Analog Sensors and
99 Addressable Modules), 4 x 20 Back-lit LCD display, 4 Class A/B (Style Z/Y) Indicating Circuits
(1.7 Amps each) and a 12 Amp power supply. Supports up to 16 Conventional Adder Modules.
Provides space for 17 Adder Modules and 3 Internal Annunciation modules. Mounts in the BBX-
1072ADS enclosure.
FX-2009-12DS Large Main Control Unit c/w one Intelligent Analog Loop Controller (99 Analog Sensors and 99
Addressable Modules), 4 x 20 Back-lit LCD display, 4 Class A/B (Style Z/Y) Indicating Circuits (1.7
Amps each) and a 12 Amp power supply. Supports up to 16 Conventional Adder Modules. Pro-
vides space for 9 Adder Modules and 3 Internal Annunciation modules. Mounts in the BB-5000
series enclosures.
ECX-0012 Expander Chassis for the FX-2009-12DS c/w space to add up to 12 adder modules and 2 Internal
Annunciation modules. Mounts in the BB-5000 series enclosures
Adder Loop Controller Modules
ALC-198S Single Loop Intelligent Analog Loop Controller Module (99 Analog Sensors and 99 Addressable Modules)
ALC-396S Dual Loop Intelligent Analog Loop Controller Module (198 Analog Sensors and 198 Addressable
Modules)
ALC-H16 Hardwire Loop Controller Module. Supports 16 Conventional Hardwired Modules
Adder Hardwire Modules
DM-1008A Eight Class B (Style B) or 4 Class A (Style D) Initiating Circuit Module
SGM-1004A Four Class A/B (Style Z/Y) Indicating Circuit Module (Rated at 1.7 Amps per circuit)
RM-1008A Eight Relay Circuit Module c/w eight form C relays (Rated for 28 VDC @ 1 Amp max. per relay)
Adder Auxiliary Modules
UDACT-300A Digital Alarm Communicator Transmitter/Dialer Module
PR-300 Polarity Reversal and City Tie Module
Programmable Modules
RAX-1048TZDS Programmable Zone LED Annunciator Module c/w 48 bi-coloured LEDs.
IPS-2424DS Programmable Input Switches Module c/w 24 selector switches and 24 bi-coloured LEDs
FDX-008 Fan Damper Control Module c/w 8 programmable switches
Remote Annunciators
RAM-1032TZDS Main Annunciator Chassis c/w Common Control Features, Indicators and 32 Bi-Coloured LEDs
RAX-1048TZDS Adder Annunciator Chassis c/w 48 Bi-Coloured LEDs
RTI-1 Remote Trouble Indicator
Remote Shared Display Annunciators
RAX-LCD Remote Shared Display LCD Annunciator c/w Display Queues and Common Controls
Graphic Annunciator Driver Modules
MGD-32 Master Graphic Driver Module c/w Fire Alarm Common Control Switch Inputs and 32 Supervised Outputs
AGD-048 Adder Graphic Driver Module c/w 48 Supervised Outputs
