PART NAMES AND FUNCTIONS
MFZ-KT25VG MFZ-KT35VG MFZ-KT50VG MFZ-KT60VG
E.O
SW
Display and operation section (When the front panel is opened)
Operation indicator lamp
Emergency operation switch
Remote control receiving section
Fan guard
Air outlet
Air cleaning filter
Air filter
Panel
Front panel
Horizontal vane
Vertical vane
Multi-flow vane
ACCESSORIES
Model
MFZ-KT25/35/50VG
-
E1
,
ET1
MFZ-KT25/35/50VG
-
ER1
,
E2
,
ET2
MFZ-KT60VG
-
E1
,
ET1
MFZ-KT60VG
-
ER1
,
E2
,
ET2
Remote controller holder 1 - 1 -
Fixing screw for 1 3.5 x 16 mm (Black) 2 - 2 -
Pipe cover 1 1 1 1
Band 2 2 2 2
Battery (AAA) for remote controller 2 2 2 2
Indoor unit mounting bracket 1 1 1 1
Fixing screw for 6 4 x 25 mm 5 5 5 5
Wood screw for the indoor unit xation 4 4 4 4
Washer of 8 4 4 4 4
Felt tape (Used for left or left-rear piping) 1 1 1 1
Wireless remote controller 1 1 1 1
Air cleaning lter 2 2 2 2
Breaker tag 1 1 1 1
Breaker notice 1 1 1 1
Joint pipe - - 1 1
Pipe cover for joint pipe - - 1 1
OBH843D
