Mitsubishi Electric MFZ-KT25VG Service Manual

8
4
SPECIFICATION
Indoor model
MFZ-KT25VG MFZ-KT35VG MFZ-KT50VG MFZ-KT60VG
Power supply Single phase 230 V, 50 Hz
Electrical data
Power input *1
Cooling
W
20 37 63
Heating 24 52 59
Running current * 1
Cooling
A
0.17 0.34 0.55
Heating 0.20 0.45 0.49
Fan motor
Model RC0J30-Q# RC0J40-P#
Current *1
Cooling
A
0.14 0.32 0.52
Heating 0.17 0.43 0.46
Dimensions W × H × D mm 750 × 600 × 215
Weight kg 14.5 15
Air direction 1 FLOW: 4, 2 FLOW: 4
Special remarks (Single)
Airow
Cooling
Super High
m
3
/h
534 738 900
High 468 624 738
Med. 390 516 576
Low 288 402 480
Silent 234 336 336
Heating
Super High
m
3
/h
582 840 876
High 438 696 750
Med. 336 564 582
Low 240 462 462
Silent 210 360 360
Sound level
Cooling
Super High
dB(A)
41 48 53
High 37 42 46
Med. 31 37 40
Low 24 32 36
Silent 19 28 28
Heating
Super High
dB(A)
44 49 51
High 37 44 47
Med. 30 40 41
Low 23 35 35
Silent 19 29 29
Fan speed
Cooling
Super High
rpm
1000 1120 1330
High 900 970 1120
Med. 770 820 900
Low 610 670 770
Silent 520 580 580
Heating
Super High
rpm
1080 1250 1300
High 850 1060 1130
Med. 690 890 910
Low 530 750 750
Silent 480 610 610
Special remarks (Multi)
Airow
Cooling
Super High
m
3
/h
540 738 900
High 468 624 738
Med. 390 516 576
Low 288 402 480
Silent 252 336 336
Heating
Super High
m
3
/h
582 840 876
High 468 696 750
Med. 378 564 582
Low 294 462 462
Silent 252 360 360
Sound level
Cooling
Super High
dB(A)
43 48 53
High 38 42 46
Med. 33 37 40
Low 28 32 36
Silent 23 28 28
Heating
Super High
dB(A)
44 49 51
High 39 44 47
Med. 34 40 41
Low 28 35 35
Silent 24 29 29
Fan speed
Cooling
Super High
rpm
1010 1120 1330
High 900 970 1120
Med. 770 820 900
Low 610 670 770
Silent 550 580 580
Heating
Super High
rpm
1080 1250 1300
High 900 1060 1130
Med. 750 890 910
Low 620 750 750
Silent 550 610 610
Fan speed regulator 5
Remote controller model SG191
OBH843D
