Mitsubishi Electric Mr.Slim PEAD-A36AA4 User Manual

67
9
CORRECTION FACTORS
PUZ-A18
PUZ-A 24/30/36
PUZ-A 42
Refrigerant piping length (one way)
30m (100ft) 40m (130ft) 50m (165ft)
20m (70ft)10m (33ft)5m (16ft)
30m (100ft) 40m (130ft) 50m (165ft)
20m (70ft)10m (33ft)5m (16ft)
Outdoor unit
PUY-A42
PUZ-A42
PUY-A24/30/36
PUZ-A24/30/36
PUY-A12/18
PUZ-A18
Outdoor unit
Refrigerant piping length (one way)
1.00
1.00
1.00
0.985
0.988
0.985
0.957
0.966
0.957
0.931
0.946
0.931
–
0.929
0.908
–
0.913
0.886
1.00
1.00
1.00
0.997
0.997
0.997
0.991
0.991
0.991
0.985
0.985
0.985
–
0.979
0.979
–
0.973
0.973
9-1-1. COOLING CAPACITY CORRECTION FACTORS
9-1-2. HEATING CAPACITY CORRECTION FACTORS
9-1-3. CAPACITY CORRECTION
Cooling and heating capacity is lowered according to pipe length. Capacity can be obtained by referring to the capacity
curves below.
Corrected pipe length (m) = actual pipe length (m) + number of bends x 0.3 (m)
Corrected pipe length (ft) = actual pipe length (ft) + number of bends x 1 (ft)
Cooling
Heating
100
95
90
85
80
75
70
5 10 15 20 25 30 35 40 45 50
<16> <33> <50> <70> <80> <100> <115> <130> <150> <165>
m
ft
Cooling A24,30,36 model
Cooling A12,18,42 models
Heating A18,24,30,36,42
models
(Up to 30m(100ft) for
A18 model)
Capacity ratio [%]
Corrected pipe length
(Up to 30m (100ft) for
A12/18 models)
9-1. INVERTER
