7
Unit: mm
MSZ-AP15VG MSZ-AP15VGK MSZ-AP20VG MSZ-AP20VGK
OUTLINES AND DIMENSIONS
5
Piping
Insulation ø35 O.D
Liquid line ø6.35 - 0.39m (Flared connection ø6.35)
Gas line ø9.52 - 0.34m (Flared connection ø9.52)
Drain hose Insulation ø29 Connected part ø16 O.D
193
60 19
155295
167.5
187.5
209
21.5
41
3
299.5
145145
335
(45)
166.5
208
61
78
42
740
760
178
5
250
335.5
14.551
100
11
96
166
80.5
50
10
(66)
505 189
INDOOR UNIT
INSTALLATION PLATE
11×26 OBLONG HOLE
11×20 OBLONG HOLE
WALL HOLE
ø 65
IN CASE OF LEFT, LEFT BACK,OR LEFT UNDER PIPING (USING SPACER), MIN 120.5mm
MIN 44.5mm
MIN 14mm
MIN 30mm
MIN 20mm
AIR IN
PIPING
DRAIN HOSE
INSTALLATION PLATE
AIR OUT
OBH838C
