45
Outdoor noise filter board
PUHZ-RP3VHA
Voltage of AC220-240V is
output. (ACL)
CN52C
52C relay signal
(Controller board)
CN5
Primary current
(Power board)
CNAC1,CNAC2
AC220-240V
(Controller board)
EI
Connect to the earth
Voltage of AC220-240V
is input. (Terminal
block)
OC294--2.qxp 03.6.9 7:37 PM Page 45
