EN-6
Name of each part and its function
Air inlet panel Air inlet
Air filters
Air outlet
Air outlet
Room
temperature
sensor
Heat exchanger
(Aluminum fin)
• Inside of the unit
Heat exchanger
(Aluminum fin)
Fan
• Inside of
the unit
Louvers
(Vertical blades)
• Left / right airflow
direction adjustment
Flaps
(Horizontal blades)
• Up / down airflow
direction adjustment
Page 18
Page 18
OUTDOOR UNIT
INDOOR UNIT
Air inlet
(back and side)
Fan
• Inside of the unit
Model name
Refrigerant pipe
and electric wire
Drain hose
Drain hole
* The appearance varies by models
IT MIGHT CAUSE INJURY.
DO NOT STEP ON TOP OF THIS UNIT.
WARNING
DO NOT INSERT ANYTHING
INTO THE AIR OUTLET.
IT MIGHT CAUSE INJURY.
DO NOT TOUCH THE
ALUMINUM FINS.
IT MIGHT CAUSE INJURY.
SHARP EDGE OF FINSMOVING FAN BLADES
CAUTION
Don't touch
the terminal
Don't touch
refrigerant
pipings and
connections.
block.
Model name
Unit display
section
Page 7
Filter holder
Filter holder
Air-cleaning filter
• Allergen clear filter
(Light orange)
• Photocatalytic washable
deodorizing filter (Orange)
RLC012A102_EN.indd 6RLC012A102_EN.indd 6 12/11/2017 11:26:06 AM12/11/2017 11:26:06 AM
