Mitsubishi Heavy Industries SC-SL2N-E User Manual

-
1
-
FDC1010KXE6
FDC1065KXE6
FDC1130KXE6
FDC1180KXE6
FDC1235KXE6
FDC1300KXE6
FDC1360KXE6
Number of connectable
2 to 59 units
2 to 62 units
2 to 66 units
3 to 69 units
3 to 72 units
3 to 76 units
3 to 80 units
Connectable capacity
504 ~ 1311
532 ~ 1384
560 ~ 1456
588 ~ 1528
615 ~ 1599
650 ~ 1690
680 ~ 1768
Item
Model
1
GENERAL INFORMATION
1.1 Specific features
(1) The new R410A refrigerant is used
The new refrigerant R410A, with an ozone destruction coefcient of zero, is used and the CO
2
discharge volume is reduced, In
addition, R410A is a pseudo-azeotropic refrigerant, so there is little change in its consistency that would cause it to divide into
the gas and liquid phases, or undergo temperature slide, and it is also possible to add refrigerant on-site.
(2) Connectable indoor capacity
Capacity from 50% to 200% is possible.
Note (1) When connecting the indoor unit type FDK, FDFL or FDFU Series, limit the connectable capacity not higher than 130%.
Capacity from 50% to 160% is possible.
Note (1) When connecting the indoor unit type FDK, FDFL or FDFU Series, limit the connectable capacity not higher than 130%.
Capacity from 50% to 130% is possible.
FDC400KXE6
FDC450KXE6
FDC504KXE6
Number of connectable
1 to 36 units
1 to 40 units
1 to 36 units
Connectable capacity
(1)
200 ~ 800
225 ~ 900
252 ~ 806
Item
Model
FDC560KXE6
FDC615KXE6
FDC680KXE6
FDC735KXE6
FDC800KXE6
FDC850KXE6
FDC900KXE6
FDC960KXE6
Number of connectable
1 to 40 units
2 to 44 units
2 to 49 units
2 to 53 units
2 to 58 units
2 to 61 units
2 to 65 units
2 to 69 units
Connectable capacity
(1)
280 ~ 896
308 ~ 984
340 ~ 1088
368 ~ 1176
400 ~ 1280
425 ~ 1360
450 ~ 1440
477 ~ 1526
Item
Model
1.2 How to read the model name
Outdoor unit
Example:
FDC 735 KX E 6
Series No.
Application power source...See the specications
Multi KX series
Nominal capacity (nominal cooling capacity : 73.5kW)
Model name (Outdoor unit)
Note
For outdoor unit, EN60552-2 and EN60555-3 are not applicable as consent by the utility company or notication to the utility
company is given before usage.
