Mitsubishi FGC20K HO User Manual

GENERAL INFORMATION
1-6
Technical Data (Standard Models)
Truck Model
Item
FGC15K
FGC18K
FGC20K
FGC25K
FGC30K
Work
performance
Rated capacity/load center
kg/mm (lb/in.)
1500/500
(3000/24)
1800/500
(3500/24)
200/500
(4000/24)
2500/500
(5000/24)
3000/500
(6000/24)
Maximum fork height mm (in.)
3300 (131)
3300 (131)
3300 (131)
Lift speed (rated load) mm/sec (fpm)
590 (116)
510 (100)
470 (93)
Lowering speed (rated load)
mm/sec (fpm)
610 (120)
550 (108)
500 (98)
Tilt angle (forward – backward)
5–10°
5–10°
5–6°
Free fork height mm (in.)
115 (4.5)
130 (5.1)
135 (5.3)
Traveling
performance
Travel speed (loaded)
km/h (mph)
Forward
15 (9.3)
16 (9.9)
16 (9.9)
Reverse
15 (9.3)
16 (9.9)
16 (9.9)
Minimum turning radius mm (in.)
1760 (69.3)
1790 (70.4)
1945 (76.6)
2002 (78.8)
2169 (85.4)
Gradeability (rated load)
[at 1.6 km/h (1 mph)] % tan
35
31
25.5
21
23
Dimensions
Overall length mm (in.)
2949 (116.1)
2980 (117.3)
4335 (170.7)
4392 (172.9)
4559 (179.5)
Overall width mm (in.)
945 (37.2)
1055 (41.5)
1105 (43.5)
Overall height
mm (in.)
To top of
mast lowered
2105 (83)
2110 (83.1)
2155 (85)
To top of
mast extended
4550 (179)
4565 (180)
4535 (176)
To top of
overhead guard
2022 (79.6)
2060 (81.1)
2060 (81.1)
Wheel base mm (in.)
1190 (46.9)
1350 (53.1)
1500 (59.1)
Tread mm (in.)
Front
793 (31.2)
877 (34.5)
902 (35.5)
Rear
826 (32.5)
922 (36.3)
897 (35.5)
897 (35.5)
Load moment constant mm (in.)
376 (14.8)
399 (15.7)
412 (16.2)
Rear overhang mm (in.)
479 (18.9)
507 (20.0)
475 (18.7)
532 (20.9)
529 (20.8)
Ground clearance (at frame)
95 (3.7)
130 (5.1)
130 (5.1)
Tire size
mm (in.)
Front
18  6  12-1/8
21  7  15
21  8  15
Rear
14  4-1/2  8
16  6  10-1/2
16  6  10-1/2
Service weight (empty) kg (lb)
2630 (5800)
3650 (8050)
4170 (9190)
Engine
Engine model
4G63
4G63
4G64
Make
Mitsubishi
Motors
Mitsubishi
Motors
Mitsubishi
Motors
Type
Gasoline
Gasoline
Gasoline
Cooling System
Water
Water
Water
No. of cylinders - arrangement
4 -in-line
4 -in-line
4 -in-line
No. of strokes
4
4
4
Types of combustion chambers
Semi-spherical
Semi-spherical
Semi-
spherical
Valve arrangement
Overhead valve
and OHC
Overhead valve
and OHC
Overhead
valve and
OHC
Type of cylinder liners
Integral with
cylinder block
Integral with
cylinder block
Integral with
cylinder
block
Cylinder bore  stroke
mm (in.)
85  88 (3.346  3.465)
85  88 (3.346  3.465)
86.5  100
(3.406  3.937)
Displacement cc (cu in.)
1997 (121.8)
1997 (121.8)
2350 (143.4)
