MPI <6A1> -
Troubleshooting
13A-191
Terminal No. Normal condition (Check condition)Inspection item
62 - 49 Intake air temperature 5.3 - 6.7 kW (When intake air temperature is 0
_
C)
sensor
2.3 - 3.0 kW (When intake air temperature is 20
_
C)
1.0 - 1.5 kW (When intake air temperature is 40
_
C)
0.30 - 0.42 kW (When intake air temperature is 80
_
C)
44 - 49 Engine coolant temperature 5.1 - 6.5 kW (When coolant temperature is 0
_
C)
sensor
2.1 - 2.7 kW (When coolant temperature is 20
_
C)
0.9 - 1.3 kW (When coolant temperature is 40
_
C)
0.26 - 0.36 kW (When coolant temperature is 80
_
C)
79 - 49 Idle position switch Continuity (when throttle valve is at idle position)
No continuity (when throttle valve is slightly open)
67 - Body Inhibitor switch <A/T> Continuity (when select lever is at P or N)
earth
No continuity (when select lever is at D, 2, L or R)
